Aflex Metal Bellows Maintenance Procedures

Metal bellows assemblies are designed for long-term operation under specified conditions with minimal intervention. When installed and operated within design parameters, bellows are generally considered maintenance-free. However, periodic inspections are recommended to ensure continued safe operation and to identify any signs of abnormal wear, damage, or environmental factors that may affect performance.

General Guidelines

E

Bellows assemblies require no routine maintenance under normal operating conditions.

E

Scheduled visual inspections should form part of the site’s general piping or plant maintenance routines.

E

Maintenance actions are typically limited to inspection and ensuring surrounding equipment does not impose unexpected loads or movements on the bellows.

Download and Print Procedures

Recommended Frequency:

Visual inspection during routine shutdowns or at least annually, unless site conditions suggest otherwise.

Inspection Steps:

Visual inspection during routine shutdowns or at least annually, unless site conditions suggest otherwise.

Visual Examination:

Inspect bellows convolutions for deformation, cracks, corrosion, or leaks.

Attachment Points:

Check welds, flanges, and tie rods for cracks, corrosion, or loose fasteners.

Alignment and Supports:

Verify pipe alignment remains within design tolerances. Confirm supports are intact.

Movement Check:

Ensure bellows are free to absorb designed movement and are not restricted.

Protective Components:

Inspect liners, covers, and insulation for damage or corrosion.

Corrective Actions

If leaks, cracks, severe deformation, or excessive corrosion are detected:

E
Isolate the system.
E
Replace the bellows assembly (bellows are generally non-repairable components).

If alignment or support issues are identified:

E
Rectify pipe misalignment or faulty supports before restarting the system.

Operational Considerations

E
Ensure system pressure, temperature, and movement stay within the bellows design limits.
E
Avoid excessive vibration, torsional loads (unless designed for torsion), or overextension beyond rated movement.

Record Keeping

Document inspection findings, including:

E
Date of inspection
E
Observations
E
Corrective actions (if any)
E

Retain inspection records as part of the plant maintenance log.

Important Notes

E
Bellows are not designed for field modification.
E
If damage or defects are suspected, consult the manufacturer before attempting repairs or replacements.
E
Replacement bellows should match the original design specifications to maintain system integrity.
